The Arduino Muscle Signal Sensor – EMG Module (Dual Supply) is a high-sensitivity bio-signal detection board designed to measure electrical activity generated by muscle contractions (Electromyography – EMG). This dual-supply version provides improved signal stability and cleaner output, making it ideal for advanced development, research, and human-machine interface projects.
By attaching surface electrodes to the skin, the module captures tiny muscle-generated electrical signals, amplifies them, and outputs a conditioned analog signal suitable for Arduino and other microcontrollers.
🔬 Key Features
-
Detects real-time muscle activity (EMG signals)
-
Dual power supply design for enhanced signal clarity
-
High-gain amplification with onboard filtering
-
Analog output compatible with Arduino & other MCU platforms
-
Compact PCB for easy integration into wearable or lab setups
-
Suitable for research, robotics, and STEM education
⚙️ Technical Specifications
-
Supply Voltage: Dual supply (e.g., ±5V or specified board requirement)
-
Output Type: Analog signal
-
Signal Type: Amplified and filtered EMG signal
-
Interface: Standard header pins
-
Compatible with: Arduino, ESP32, STM32, Raspberry Pi (via ADC), etc.
🧠 Applications
-
Muscle-controlled robotics
-
Prosthetic device development
-
Gesture recognition systems
-
Biomedical signal processing
-
Human-computer interaction projects
-
University research and lab experiments
📦 Package Includes
-
1 × Arduino Muscle Signal Sensor – EMG Dual Supply Module
⚠ Disclaimer: This module is intended for educational, experimental, and development use only. It is not a certified medical device.
A powerful solution for exploring bioelectronics and building innovative muscle-controlled systems.
